SMPH
Single Filter
SMPH-10/12 Series
Weight (including element)：
Type 1：2.56 kg
Type 2：2.95 kg
Type 3：3.52 kg
Max. flow：350 l/min
Working pressure：70 kg/cm²
Material
Head: aluminium alloy
Bowl: aluminium alloy
| Model No. | A mm |
B mm |
C mm |
*Weight kg |
|
| SE-SMP | Type 1 | 85 | 47.5 | 145 | 0.56 |
|---|---|---|---|---|---|
| Type 2 | 85 | 47.5 | 205 | 0.64 | |
| Type 3 | 85 | 47.5 | 257 | 0.78 | |
*A40 μ glass fiber
